If you have the need to quickly pull together a simple view for a diagram, document or drawing, there’s no need to spin up a modelling tool or wrestle with Vision (or more likely wrestle with your IT department to get them to install Vision for you!) Look no further than UMLet (That’s https://www.umlet.com/ )

I’ve been using it for years but just thought it a good idea to mention it here.

It’s pretty simple to get the hang of, and using text based programming makes it really easy to copy and paste areas of your diagram. Take a look at a simple Sequence Diagram I pulled together in about 5 minutes:

Which have the underlying code of:

title: Combining Private and Public Primitives
SUBMITTER~id1|SERVICE (Private)~id2|SERVICE (Public)~id3|SIP (Private)~id4|SIP (Public)~id5|COMPOSITOR (Public)~id6|EVALUATOR (Public)~id7

iframe{:Registering a Private Service with a Private SIP (Out of Band)

id2->id4:id2,id4:Service Contract
id4->id4:id4,id4:Register and store
id2->id4:id2,id4:Service Contract (update TTL, Location)
id4->id4:id4,id4:Update
iframe}

iframe{:Registering a Public Service with a Public SIP (Out of Band)

id3->id5:id3,id5:Service Contract
id5->id5:id5,id5:Register and store
id3->id5:id3,id5:Service Contract (update TTL, Location)
id5->id5:id5,id5:Update
iframe}

iframe{:Finding available SERVICEs
id1->id4:Request for Service Contract
id4->id4:id4: Find the Service Contract
id4->id1:Service Contract

id1->id5:Request for Service Contract
id5->id5:id5: Find the Service Contract
id5->id1:Service Contract
iframe}

iframe{:Using SERVICEs and evalutating risk
id1->id2:Input (to be kept private)
id2->id2:id2: Evaluate Input for risk
id2->id1:Service Result (a)

id1->id3:Input (to can be used in public)
id3->id3:id3: Evaluate Input for risk
id3->id1:Service Result (b)

id1->id6:Service result (a) + Existing Risk Profile
id6->id6:id6: Combined Service Result and Risk Profile
id6->id1:Risk Profile

id1->id6:Service result (a) + Existing Risk Profile
id6->id6:id6: Combined Service Result and Risk Profile
id6->id1:Risk Profile

id1->id7:Risk Profile
id7->id7:id7: Evaluate Risk Profile
id7->id1:Mitigation

iframe}

Enjoy!
